● HOUNSFIELD H25K-T BENCHTOP Materials testing Machines
중고인장강도시험기,UTM H25KT
[특징]
• PC control
via high speed RS232 using ASCII and super high speed binary
modes
• Force
accuracy of 0.5% of applied load across the load cell display range
• 32 bit
precision motor controller
•
Displacement resolution of 0.0001 mm (T series in binary mode)
• Speed
resolution of 0.001 mm/min
• 150%
mechanical overload on load cells
• 20%
digital load tare while maintaining full load cell capacity
• Automatic
motor alarms monitor over/ under voltage, current and
temperature
• Built-in
intelligent active force and displacement alarm system
[사양]
Load
measurement accuracy: +/- 0.5% of indicated load from 2% to 100% capacity;
extended range down to 1% capacity
with accuracy of 1% of indicated load Position
measurement accuracy: +/- 0.01% of reading or 0.001 mm, whichever is greater Speed
accuracy: +/- 0.005% of set speed
Operating
temperature range: 32 to 100 degrees F (0 to 38 degrees C)
Storage
temperature range: 14 to 115 degrees F (-10 to 45 degrees C)
Humidity
range: 10% to 90% non-condensing, wet bulb method
Power:
standard optional voltages 220/240VAC, 50-60 Hz, 2000W; power must be free of
spikes and surges exceeding 10% of the
nominal voltage
■ 중고 제품은 회전이 빠르므로 유선통화상 재고 유무를 확인해주시길 바랍니다.
■ 본 장비는 사전에 약속하시면 데모 및 샘플측정이 가능하니 방문전 전화부탁드
립니다.
■ 저희는 신품판매를 주로 하고 있으며, 중고품은 업체에 요구나 재고 가 있을
경우 판매하고 있습니다.
